D1: Diagnostics tools
5.6 Identifying defective drive modules
Basic Functions
294 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Example
The 2axis module with drive numbers "1" and "2" must be removed from a drive grouping.
Module "2" must now be removed:
• Machine datum:
MD13030 $MN_DRIVE_MODULE_TYPE
is to be selected on the "General MD" MD screen.
• DRIVE_MODULE_TYPE[0] = 1
DRIVE_MODULE_TYPE[1] = 2 <- set this entry to zero
DRIVE_MODULE_TYPE[2] = 2 <- set this entry to zero
DRIVE_MODULE_TYPE[3] = 2
DRIVE_MODULE_TYPE[4] = 2
DRIVE_MODULE_TYPE[5] = 1
DRIVE_MODULE_TYPE[6] = 9
• After the changes, the table looks like this:
DRIVE_MODULE_TYPE[0] = 1
DRIVE_MODULE_TYPE[1] = 0
DRIVE_MODULE_TYPE[2] = 0
DRIVE_MODULE_TYPE[3] = 2
DRIVE_MODULE_TYPE[4] = 2
DRIVE_MODULE_TYPE[5] = 1
DRIVE_MODULE_TYPE[6] = 9
• Alarms 300020 "Drive 1 removed for diagnostics" and 300020 "Drive 2 removed for diagnostics" are
displayed.
Note
Before activating the function, the module in question must be removed from the drive bus
configuration
(SIMODRIVE 611 digital). To do this, connect the drive bus so as to exclude the module.
If Safety Integrated has been activated for the modules concerned, you must disable it
manually (safety, logged, EMERGENCY STOP scheme).
Table 5-5 Bus configuration example
Module Drive no. Active Type Module type Power section code
1 10 1 ARM/MSD Axis 6
Left 1 1 SRM/FDD Axis 14
Right 2 1 SRM/FDD Axis 14
Left 4 1 HLA Axis
Right 5 1 ANA Axis
4 12 1 SLM Axis 11
5 11 1 PER DMPC
