D1: Diagnostics tools
5.7 Data lists
Basic Functions
298 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Fixed stop reached DB31, ... .DBX62.5 DB390x.DBX2.5
Setup mode active DB31, ... .DBX92.0 -
Rampup function generator quick stop DB31, ... .DBX92.1 -
Torque limit 2 active DB31, ... .DBX92.2 -
Speed setpoint smoothing active DB31, ... .DBX92.3 -
Active parameter set A, B, C DB31, ... .DBX93.0-2 DB390x.DBX4001.0-2
Active motor A, B DB31, ... .DBX93.3/4 -
Drive Ready DB31, ... .DBX93.5 DB390x.DBX4001.5
Speed controller integrator disabled DB31, ... .DBX93.6 DB390x.DBX4001.6
Pulses enabled DB31, ... .DBX93.7 DB390x.DBX4001.7
Motor temperature prewarning DB31, ... .DBX94.0 DB390x.DBX4002.0
Heat-sink temperature prewarning DB31, ... .DBX94.1 DB390x.DBX4002.1
Ramp-up function completed DB31, ... .DBX94.2 DB390x.DBX4002.2
_'M
d
_'< M
dx
DB31, ... .DBX94.3 DB390x.DBX4002.3
_'n
act
_'< n
min
DB31, ... .DBX94.4 DB390x.DBX4002.4
_'n
act
_'< n
x
DB31, ... .DBX94.5 DB390x.DBX4002.5
_'n
act
_'= n
set
DB31, … .DBX94.6 DB390x.DBX4002.6
Signal name SINUMERIK 840D sl SINUMERIK 828D
