Siemens SINUMERIK 828D Function Manual

F1: Travel to fixed stop
6.4 Examples
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
325
Multiple selection
A selection may only be carried out once. If the function is called once more due to faulty programming
(FXS[Axis]=1) the alarm 20092 "Travel to fixed stop still active" is initiated.
Programming code that scans $AA_FXS[] or a separate flag (here R1) in the condition will ensure that the
function is not activated more than once.
programming example (parts program fragment):
Blockrelated synchronized actions
By programming a blockrelated synchronized action, travel to fixed stop can be connected during an approach
motion.
Programming example:
N10 R1=0
N20 IDS=1 WHENEVER ($R1 == 0 AND $AA_IW[AX3]>7) DO R1=1 FXS[AX1]=1
FXST[AX1] = 12
N10 G0 G90 X0 Y0
N20 WHEN $AA_IW[X]>17 DO FXS[X]=1 ; If X reaches a position greater
N30 G1 F200 X100 Y110 ; 17mm FXS is activated

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
