G2: Velocities, setpoint / actual value systems, closed-loop control
7.3 Metric/inch measuring system
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
343
Reading and writing of data in the case of G70/G71 and G700/G710 in the part program
Reference:
/PG/Programming Manual, Fundamentals; List of Addresses
Data area G70/G71 G700/G710
ReadWriteReadWrite
Display, decimal places (WCS) P P P P
Display, decimal places (MCS) GGGG
Feedrates G G P P
Positional data X, Y, Z P P P P
Interpolation parameters I, J, K P P P P
Circle radius (CR) P P P P
Polar radius (RP) P P P P
Pitch PPPP
Programmable FRAME P P P P
Settable FRAMES G G P P
Basic frames G G P P
Work offsets external G G P P
Axial preset offset G G P P
Operating range limit (G25/G26)GGPP
Protection zones P P P P
Tool offsets G G P P
Length-related machine data G G P P
Length-related setting data G G P P
Length-related system variables G G P P
GUD GGGG
LUD GGGG
PUD GGGG
R parameters GGGG
Siemens cycles P P P P
Jog/handwheel increment factor GGGG
P: Data is read/written in the programmed measuring system
G: Writing/reading takes place in the configured basic system.
NOTICE
Read position data in synchronized actions
If a measuring system has not been explicitly programmed in the synchronized action
(condition component and/or action component) length-related position data in the
synchronized action are always read in the parameterized basic system.
