Siemens SINUMERIK 828D Function Manual

G2: Velocities, setpoint / actual value systems, closed-loop control
7.5 Closed-loop control
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
379
Parameter sets during gear stage change
Interpolation parameter sets during gear stage change:
In the case of spindles, each gear stage is assigned its own parameter set.
Dependent on the NC/PLC interface signal:
DB31, ... DBX16.0 - 16.2 (actual gear stage)
the corresponding parameter set is activated.
For more information on gear stages for spindles see:
References:
/FB1/ Function Manual Basic Functions; Spindles (S1)
DB31, ... DBX16.0 - 16.2 (actual gear stage) Active parameter set
000 1. Gear stage 2 (Index=1)
001 1. Gear stage 2 (Index=1)
010 2. Gear stage 3 (Index=2)
011 3. Gear stage 4 (Index=3)
100 4. Gear stage 5 (Index=4)
101
110
111
5. Gear stage 6 (Index=5)
