H2: Auxiliary function outputs to PLC
8.1 Brief description
Basic Functions
394 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
• The predefined auxiliary functions M0, M1, M17, M30, M6, M4, M5 cannot be redefined.
• M function-specific machine data:
MD10800 $MN_EXTERN_CHAN_SYNC_M_NO_MIN
MD10802 $MN_EXTERN_CHAN_SYNC_M_NO_MAX
MD10804 $MN_EXTERN_M_NO_SET_INT
MD10806 $MN_EXTERN_M_NO_DISABLE_INT
MD10814 $MN_EXTERN_M_NO_MAC_CYCLE
MD10815 $MN_EXTERN_M_NO_MAC_CYCLE_NAME
MD20094 $MC_SPIND_RIGID_TAPPING_M_NR
MD20095 $MC_EXTERN_RIGID_TAPPING_M_NR
MD20096 $MC_T_M_ADDRESS_EXT_IS_SPINO
MD22200 $MC_AUXFU_M_SYNC_TYPE
MD22530 $MC_TOCARR_CHANGE_M_CODE
MD22532 $MC_GEOAX_CHANGE_M_CODE
MD22534 $MC_TRAFO_CHANGE_M_CODE
MD22560 $MC_TOOL_CHANGE_M_CODE
S functions
Application
Spindle speed.
Further information
S (spindle function)
Address extension Value
Value range Meaning Value range Type Meaning
Number
8)
0 ... 20
Spindle number
5)
0 ... ± 3.4028 exp38
3)
REAL Spindle speed 3
Remarks:
The master spindle of the channel is addressed if no an address extension is specified.
3)
,
5)
,
8)
See "Meaning of footnotes" at the end of the overview.
