H2: Auxiliary function outputs to PLC
8.2 Predefined auxiliary functions
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
411
Tool change 298 M 18
6
1)
166
Tool change 299 M 19
6
1)
167
Tool change 300 M 20
6
1)
168
(
)
The value can be changed.
1)
The value is depends on the machine data:
MD22560 $MC_TOOL_CHANGE_M_MODE (M function for tool change)
2)
The value can be preset with a different value using the following machine data:
MD20095 $MC_EXTERN_RIGID_TAPPING_M_NR (M function for switching over to the
controlled axis mode (ext. mode))
MD20094 $MC_SPIND_RIGID_TAPPING_M_NR (M function for switching over to
controlled axis mode)
Note
The value 70 is always output to the PLC.
3)
The value is set using machine data:
MD22254 $MC_AUXFU_ASSOC_M0_VALUE (additional M function for program stop)
4)
The value is set using machine data:
MD22256 $MC_AUXFU_ASSOC_M1_VALUE (additional M function for conditional
stop)
5)
The value is set using machine data:
MD10714 $MN_M_NO_FCT_EOP (M function for spindle active after reset)
6)
The value is set using machine data:
MD26008 $MC_NIBBLE_PUNCH_CODE (definition of M functions)
Tool holder-specific auxiliary functions, M6 auxiliary functions
System function Index <n> Type
Address
extension
Value Group
