Siemens SINUMERIK 828D Function Manual

H2: Auxiliary function outputs to PLC
8.7 Programming an auxiliary function
Basic Functions
432 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
H5 ; Output to PLC: H0=5
H=5.379 ; Output to PLC: H0=5.379
H17=3.5 ; Output to PLC: H17=3.5
H[coolant]=13.8 ; Output to PLC: H12=13.8
H='HFF13' ; Output to PLC: H0=65299
H='B1110' ; Output to PLC: H0=14
H5.3=21 ; Error
Program code Comment

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
