Siemens SINUMERIK 828D

H2: Auxiliary function outputs to PLC
8.13 Block-search response
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
455
Example 2: Deleting auxiliary functions and generating the auxiliary function output without AUXFUSYNC(...)
N320 IF (NUM==-1) ;
;
All auxiliary functions of the channel
have been executed.
N340 GOTOF LABEL1
N350 ENDIF
N380 WRITE(ERROR,FILENAME,ASSEMBLED) ; Write a part program block to file FILENAME.
N390 IF (ERROR<>0) ; Error evaluation
N400 SETAL(61000+ERROR)
N410 ENDIF
N430 ENDLOOP
N440
N450 LABEL1:
N460
N480 CALL FILENAME ; Process a generated subroutine.
N490
N510 DELETE(ERROR,FILENAME) ; Delete the file again after execution.
N520 IF (ERROR<>0)
N530 SETAL(61000+ERROR)
N540 ENDIF
N550
N560 M17
Program code Comment
N0610 DEF STRING[400] ASSEMBLED=""
N0620 DEF STRING[31] FILENAME="/_N_CST_DIR/_N_AUXFU_SPF"
N0630 DEF INT GROUPINDEX[10]
N0640 DEF INT NUM
N0650 DEF INT LAUF
N0660 DEF INT ERROR
N0670 DEF BOOL ISQUICK
N0680 DEF BOOL ISSYNACT
N0690 DEF BOOL ISIMPL
...
N0760 AUXFUDEL("M",2,3,5) ; M2=3 (5th auxiliary function group) delete
N0770
Program code Comment
