H2: Auxiliary function outputs to PLC
8.18 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
475
Extended address M function 3 (16 bit int) DB21, ... .DBB80-81 DB2500.DBB3020
M function 3 (DInt) DB21, ... .DBB82-85 DB2500.DBD3016
Extended address M function 4 (16 bit int) DB21, ... .DBB86-87 DB2500.DBB3028
M function 4 (DInt) DB21, ... .DBB88-91 DB2500.DBD3024
Extended address M function 5 (16 bit int) DB21, ... .DBB92-93 DB2500.DBB3036
M function 5 (DInt) DB21, ... .DBB94-97 DB2500.DBD3032
Extended address S function 1 (16 bit int) DB21, ... .DBB98-99 DB2500.DBB4004
S function 1 (real) DB21, ... .DBB100-103 DB2500.DBD4000
Extended address S function 2 (16 bit int) DB21, ... .DBB104-105 DB2500.DBB4012
S function 2 (real) DB21, ... .DBB106-109 DB2500.DBD4008
Extended address S function 3 (16 bit int) DB21, ... .DBB110-111 DB2500.DBB4020
S function 3 (real) DB21, ... .DBB112-115 DB2500.DBD4016
Extended address T function 1 (16 bit int) DB21, ... .DBB116-117 DB2500.DBB2004
T function 1 (integer) DB21, ... .DBB118-119 DB2500.DBD2000
Extended address T function 2 (16 bit int) DB21, ... .DBB120-121 -
T function 2 (integer) DB21, ... .DBB122-123 -
Extended address T function 3 (16 bit int) DB21, ... .DBB124-125 -
T function 3 (integer) DB21, ... .DBB126-127 -
Extended address D function 1 (8 bit int) DB21, ... .DBB128 DB2500.DBB5004
D function 1 (8 bit int) DB21, ... .DBB129 DB2500.DBD5000
Extended address D function 2 (8 bit int) DB21, ... .DBB130 -
D function 2 (8 bit int) DB21, ... .DBB131 -
Extended address D function 3 (8 bit int) DB21, ... .DBB132 -
D function 3 (8 bit int) DB21, ... .DBB133 -
Extended address DL function (8 bit int) DB21, ... .DBB134 -
DL function (real) DB21, ... .DBB136 -
Extended address H function 1 (16 bit int) DB21, ... .DBB140-141 DB2500.DBB6004
H function 1 (real or DInt) DB21, ... .DBB142-145 DB2500.DBD6000
Extended address H function 2 (16 bit int) DB21, ... .DBB146-147 DB2500.DBB6012
H function 2 (REAL or DInt) DB21, ... .DBB148-151 DB2500.DBD6008
Extended address H function 3 (16 bit int) DB21, ... .DBB152-153 DB2500.DBB6020
H function 3 (real or DInt) DB21, ... .DBB154-157 DB2500.DBD6016
Extended address F function 1 (16 bit int) DB21, ... .DBB158-159 -
F function 1 (real) DB21, ... .DBB160-163 -
Extended address F function 2 (16 bit int) DB21, ... .DBB164-165 -
F function 2 (real) DB21, ... .DBB166-169 -
Extended address F function 3 (16 bit int) DB21, ... .DBB170-171 -
F function 3 (real) DB21, ... .DBB172-175 -
Extended address F function 4 (16 bit int) DB21, ... .DBB176-177 -
F function 4 (real) DB21, ... .DBB178-181 -
Extended address F function 5 (16 bit int) DB21, ... .DBB182-183 -
Signal name SINUMERIK 840D sl SINUMERIK 828D
