K1: Mode group, channel, program operation, reset response
9.8 Block search Type 5 SERUPRO
Basic Functions
522 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Basic G function settings for SERUPRO
Machine data:
MD20112 $MC_START_MODE_MASK
is used to define the channel-specific basic settings after a program start for various G functions, e.g. the actual
plane, adjustable work offset, active tool length compensation, active kinematic transformation etc.
For SERUPRO, using machine data:
MD22620 $MC_START_MODE_MASK_PRT
you can enter your own basic setting. The structure of machine data MD22620 is identical with that of MD20112.
The SERUPRO-specific G function initial settings are enabled using machine data:
MD22621 $MC_ENABLE_START_MODE_MASK_PRT
NC/PLC interface signal "Block search via program test is active"
The block search via program test is displayed using the NC/PLC interface signal:
DB21, ... DBX318.1 = 1
The interface signal is set from the start of the block search until the target block is inserted into the main run.
4 0 The overrides (channel, axis, spindle) specified via the NC/PLC interface are active
during SERUPRO.
1 The overrides (channel, axis, spindle) specified via the NC/PLC interface are not active
during SERUPRO.
Note
The programmable overrides, e.g. OVR, are active during SERUPRO.
5 0 The "Single block" function is active during SERUPRO.
1 The "Single block" function is not active during SERUPRO.
Bit Valu
e
Meaning
0 0 After the part program start, MD20112 $MC_START_MODE_MASK becomes active
1 After the part program start, MD22620 $MC_START_MODE_MASK_PRT becomes
active
