Systems with tool management and auxiliary spindle are not supported by SERUPRO!
Example
Tool change subroutine
ASUB for calling the tool change routine after block search type 5
PROC L6 ; Tool change routine
N500 DEF INT TNR_AKTUELL ; Variable for active T number
N510 DEF INT TNR_VORWAHL ; Variable for preselected T number
; Determine current tool
N520 STOPRE ; In program testing
N530 IF $P_ISTEST ; from the program context
N540 TNR_AKTUELL = $P_TOOLNO ; the "current" tool is read.
N550 ELSE ; Otherwise, the tool of the spindle
is read out.
N560 TNR_AKTUELL = $TC_MPP6[9998,1] ; Read tool T number on the spindle
N570 ENDIF
N580 GETSELT(TNR_VORWAHL) ; Read T number of preselected tool
of the master spindle. Execute tool
change only if tool not yet
current.
N590 IF TNR_AKTUELL <> TNR_VORWAHL ; Approach tool change position
N600 G0 G40 G60 G90 SUPA X450 Y300 Z300 D0
N610 M206 ; Execute tool change
N620 ENDIF
N630 M17
PROC ASUPWZV2
N1000 DEF INT TNR_SPINDEL ; Variable for active T number
N1010 DEF INT TNR_VORWAHL ; Variable for preselected T number
N1020 DEF INT TNR_SUCHLAUF ; Variable for T number determined in
block search
N1030 TNR_SPINDEL = $TC_MPP6[9998,1] ; Read tool T number on the spindle
N1040 TNR_SUCHLAUF = $P_TOOLNO ; read T number determined by search
run, i.e., that tool determines the
current tool offset.
N1050 GETSELT(TNR_VORWAHL) ; Read T number of preselected tool
N1060 IF TNR_SPINDEL ==TNR_SUCHLAUF GOTOF
ASUP_ENDE1
;
N1070 T = $TC_TP2[TNR_SUCHLAUF] ; T selection by tool name
N1080 L6 ; Call tool change routine
;
