K1: Mode group, channel, program operation, reset response
9.9 Program operation mode
Basic Functions
590 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Stop criteria
A stop event can be triggered by the following
Conditions
The following conditions apply while a stop delay area is being processed:
A change in the feed is ignored while in the stop delay area. A feed disable is thus not effective until the
program area has been exited, and is stopped.
None of the main run axes, such as command axes and positioning axes, which are traversed with POSA, is
stopped.
Part program command G4 is permitted in the stop delay area.
Other part program commands that cause a stop in the meantime (e.g. WAITM), are not permitted and trigger
the alarm 16954.
A stop delay section entered with an override of 0% will not be accepted!
VDI interface signals from the PLC "Hard" stop event
Alarms with NOREADY response "Hard" stop event
Stop key "Soft" stop event
Read-in disable "Soft" stop event
Single BLock "Soft" stop event
Note
Some NCK events are stopped for a short time, in order to perform a switching operation,
and restart immediately. These include e.g. the ASUB that stops the contour briefly in order
to then start the ASUB program immediately. These events are also allowed in the stop delay
area, however they are pushed back to its end and are thus considered "soft stop events".
