Page #610 background imageLoading...
Page #610 background image
K1: Mode group, channel, program operation, reset response
9.12 Single block
Basic Functions
610 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Cycle
Example 1:A cycle is to act like a command for a user.
Main program:
Program cycle:1
CYCLE1 is processed for an active single block, i.e., the Start key must be pressed once to process CYCLE1.
Example 2: An ASUB, which is started by the PLC in order to activate a modified zero offset and tool offsets, is to
be executed invisibly.
N10 G1 X10 G90 F200
N20 X-4 Y6
N30 CYCLE1
N40 G1 X0
N50 M30
N100 PROC CYCLE1 DISPLOF SBLOF ; Suppress single block
N110 R10=3*SIN(R20)+5
N120 IF (R11 <= 0)
N130 SETAL(61000)
N140 ENDIF
N150 G1 G91 Z=R10 F=R11
N160 M17
N100 PROC ZO SBLOF DISPLOF
N110 CASE $P_UIFRNUM OF 0 GOTOF
_G500 1 GOTOF _G54 2 GOTOF _G55 3 GOTOF _G56 4
GOTOF _G57 DEFAULT GOTOF END
N120 _G54: G54 D=$P_TOOL T=$P_TOOLNO
N130 RET
N140 _G54: G55 D=$P_TOOL T=$P_TOOLNO
N150 RET
N160 _G56: G56 D=$P_TOOL T=$P_TOOLNO
N170 RET
N180 _G57: G57 D=$P_TOOL T=$P_TOOLNO
N190 RET
N200 END: D=$P_TOOL T=$P_TOOLNO
N210 RET
