Siemens SINUMERIK 828D Function Manual

K2: Axis Types, Coordinate Systems, Frames
10.4 Coordinate systems
Basic Functions
710 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
The following coordinate systems are defined:
Interrelationships between coordinate systems
The coordinate systems are determined by the kinematic transformation and the FRAMES.
A kinematic transformation is used to derive the BCS from the MCS. If no kinematic transformation is active, the
BCS is the same as the MCS.
The basic frame maps the BCS onto the BKS.
An activated adjustable FRAME G54...G599 ENS is derived from the BNS.
The WCS, which is the basis for programming, is defined by the programmable FRAME.
MCS Machine Coordinat System
BCS Basic Coordinate System
BZS Basic Zero System
SZS Settable Zero System
WCS Workpiece Coordinate System

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
