K2: Axis Types, Coordinate Systems, Frames
10.5 Frames
Basic Functions
792 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
N110 $TC_CARR9[1] = 0 ; Z components of 1st axis
N120 $TC_CARR10[1] = 0 ; X components of 2nd axis
N130 $TC_CARR11[1] = 1 ; Y components of 2nd axis
N140 $TC_CARR12[1] = 0 ; Z components of 2nd axis
N150 $TC_CARR13[1] = 30. ; Angle of rotation of 1st axis
N160 $TC_CARR14[1] = -30. ; Angle of rotation of 2nd axis
N170 $TC_CARR15[1] = 0 ; X components of 3rd offset vector
N180 $TC_CARR16[1] = 0 ; Y components of 3rd offset vector
N190 $TC_CARR17[1] = 0 ; Z components of 3rd offset vector
N200 $TC_CARR18[1] = 0 ; X components of 4th offset vector
N210 $TC_CARR19[1] = 0 ; Y component of 4th offset vector
N220 $TC_CARR20[1] = 15. ; Z components of 4th offset vector
N230 $TC_CARR21[1] = A ; Reference for 1st axis
N240 $TC_CARR22[1] = B ; Reference for 2nd axis
N250 $TC_CARR23[1] = "M" ; Toolholder type
N260 X0 Y0 Z0 A0 B45 F2000
N270 TCARR=1 X0 Y10 Z0 T1 TCOABS ; Selection of orient. toolholder
N280 PAROT ; Rotation of table
N290 TOROT ; Rotation of z axis in tool orient.
N290 X0 Y0 Z0
N300 G18 MOVT=AC(20) ; Processing in G18 plane
N310 G17 X10 Y0 Z0 ; Processing in G17 plane
N320 MOVT=-10
N330 PAROTOF ; Deactivate rotation of table
N340 TOROTOF ; No longer align WCS with tool
N400M30
