P1: Transverse axes
12.1 Brief description
Basic Functions
826 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Several transverse axes in the channel
The introduction several transverse axes in the channel involves a functional decoupling of diameter
programming and reference axis for G96/G961/G962. Diameter programming and reference axis for G96/G961/
G962 can be active for different transverse axes (see table below).
Programming the transversing paths
The traverse paths of a transverse axis programmed in the part program may be either radius- or diameter-
based. It is possible to switch between the two reference types with the part program commands DIAMON
(DIAMeter ON = diameter) and DIAMOF (DIAMeter OF = radius). In this way, dimensional information can be
taken directly from the technical drawing without conversion.
Programming and display
in the diameter
Reference axis for
G96/G961/G962
Permissible axis type: Geometry axis Linear channel
axes
Geometry axis
Selection in the channel one m of 3 m of n one one of 3
Specific effect:
Machine data:
Channel
MD20100
Axis
MD30460
Channel
MD20100
Programming:
DIAM*
channel-specific modal
G group 29
SCC[AX]
channel-specific modal
Reference axis for G96/G961/G962
Acceptance during axis
replacement:
DIAM*A[AX]
axis-specific modal
Axis-specific non-modal
diametral/radius
programming
DAC, DIC; RAC, RIC
blockwise axis-specific only programming
DIAM*: DIAMOF, DIAMON, DIAM90, DIAMCYCOF
DIAM*A[AX]: DIAMOFA[AX], DIAMONA[AX], DIAM90A[AX], DIACYCOFA[AX], DIAMCHANA[AX]
AX: Axis identifier for geometry/channel or machine axis identifier
Note
Rotary axes are not permitted to serve as transverse axes.
