P3: Basic PLC Program for SINUMERIK 840D sl
13.13 Block descriptions
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
965
For a symmetric search (see parameter "SearchDirection")
• the search area may stretch over only a single magazine (cases 2 and 5 from the above table). If another
search domain is specified, the service will malfunction.
• a reference location must be entered in the parameters "MagNrRef" and "PlaceNrRef", with respect to which
the symmetric search is done.
The reference location is a buffer location (a location from the magazine buffer, i.e. change position, gripper, etc.)
or a load point (a location from the internal loading magazine). The search is executed symmetrically with
reference to the magazine location in front of the specified reference location. A multiple assignment to the
magazine being searched must be configured in the TPM block for the reference location. If this is not the case,
a malfunction occurs. If the magazine location in front of the reference location is outside the search domain, the
service responds as if it has not found a matching location.
#M1 #P1 #M1 -1 Locations in magazine #M1 starting at
magazine #M1 and location #P1 in this
magazine are searched
#M1 #P1 #M2 -1 Locations starting at magazine #M1 and
location #P1 up to magazine #M2 are
searched
#M1 -1 #M2 #P2 Locations starting at magazine #M1 up to
magazine #M2, location #P2 are searched
#M1 -1 #M2 -1 Locations starting at magazine #M1 up to and
including magazine #M2 are searched
-1 -1 -1 -1 All magazine locations are searched
Note
Before and after this PI service, the MMCSEM PI service must be called up with the
associated parameter WVar1 for this PI service. See PI service MMCSEM for more
information.
Parameterization
Signal Type Value range Meaning
PIService ANY PI.TSEARC Complex search using search screen forms
Unit INT 1 ... 10 TOA
WVar1 INT MagNrFrom Magazine number of magazine from which
search must begin
WVar2 INT PlaceNrFrom Location number of location in magazine
MagNrFrom, at which search must begin
WVar3 INT MagNrTo Magazine number of magazine at which search
must end
WVar4 INT PlaceNrTo Location number of location in magazine
MagNrTo, at which search must end
WVar5 INT MagNrRef Magazine number of (internal) magazine, with
reference to which the symmetrical search is to be
performed. (this parameter is only relevant with a
"symmetrical" search direction)
MagNr
From
PlaceNr
From
MagNr
To
PlaceNr
To
Search area
