P3: Basic PLC Program for SINUMERIK 840D sl
13.13 Block descriptions
Basic Functions
980 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
#M1 #P1 #M2 #P2 Locations starting at magazine #M1, location
#P1 up to magazine #M2, location #P2 are
searched
#M1 -1 #M1 -1 All locations in magazine #M1 - and no
others - are searched
#M1 -1 -1 -1 All locations starting at magazine #M1 are
searched
#M1 #P1 -1 -1 All locations starting at magazine #M1 and
location #P1 are searched
#M1 #P1 #M1 -1 Locations in magazine #M1 starting at
magazine #M1 and location #P1 in this
magazine are searched
#M1 #P1 #M2 -1 Locations starting at magazine #M1, location
#P1 up to magazine #M2, location #P2 are
searched
#M1 -1 #M2 #P2 Locations starting at magazine #M1 up to
magazine #M2, location #P2 are searched
#M1 -1 #M2 -1 Locations starting at magazine #M1 up to
and including magazine #M2 are searched
-1 -1 -1 -1 All magazine locations are searched
Note
Before and after this PI service, the MMCSEM PI service must be called up with the
associated parameter WVar1 for this PI service. See PI service MMCSEM for more
information.
Parameterization
Signal Type Range of values Significance
PIService ANY PI.TMFPBP Empty location search
Unit INT 1 ... 10 TOA
WVar1 INT MagazinNumber_From
Magazine number of magazine, from which
search must begin
WVar2 INT LocationNumber_From:
Location number of location in magazine
MagazineNumber_From, at which search must
begin
WVar3 INT MagazineNumber_To:
Magazine number of magazine, at which
search must end
WVar4 INT LocationNumber_To:
Location number of location in magazine
MagazineNumber_To, at which search must
end
WVar5 INT MagazineNumber_Ref:
WVar6 INT LocationNumber_Ref:
Magazine
Number
_From
Location
Number
_From
Magazine Number
_To
Location
Number
_To
Search area
