7.1.5 Technical data
MCP 483 USB
Parameter Value
Input voltage 5 V DC
Power consumption, max. 2.5 W
Vibratory load:
● Operation
● Transportation (in transportation packaging)
10 – 58 Hz: 0.35 mm/58 - 200 Hz: 1 g
(3M6 acc. to EN 60721-3-3)
5 – 9 Hz: 3.5 mm/9 - 200 Hz: 1 g
(2M3 acc. to EN 60721-3-2)
Shock load:
● Operation
● Transportation (in transportation packaging)
10 g, 6 ms, 6 shocks (acc. to EN 60721-3-3)
10 g, 6 ms, 100 shocks (acc. to EN 60721-3-2)
Protection class acc. to EN 61800-5-1 III (DVC A, PELV)
Degree of protection acc. to DIN IEC 529 IP65 (front)
IP20 (rear)
Cooling By natural convection
Temperature limits:
● Storage
● Transportation (in transportation packaging)
● Operation:
– Front
– Rear
-25 °C ... +55 °C
-40 °C ... +70 ºC
0 ... +45 ºC
0 ... +55 ºC
Relative humidity:
● Storage
● Transportation
● Operation
5 ... 95 %
5 ... 95 %
5 ... 85 %
Condensation, spraying water, and icing Not permissible
Supply air Without aggressive gases, dusts, and oils
Approvals CE, cULus, KCC, EAC, C-Tick
Dimensions:
● Width
● Height
● Depth
483 mm
155 mm
49 mm
Weight: 1.22 kg
See also
Other values/standards: Application planning (Page 35)
Anschließbare Komponenten
7.1 MCP 483 USB
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 103
