Digital outputs min. Typical max. Nominal
Leakage current at low level -- 50 μA 400 μA --
Signal delay time T
PHL
-- 0.5 ms -- --
Maximum switching frequency
Resistive load -- -- 100 Hz --
Inductive load -- -- 2 Hz --
Lamp -- -- 11 Hz --
1)
U
H_typical
= V
CC
- I
OUT
× R
ON
V
CC
: Current operating voltage
I
OUT
: Output current
Maximum short-circuit current: 4 A (max. 100 μs, V
CC
= 24 V)
R
ON
: Maximum internal resistance = 0.4 Ω
2)
Where demand factor is 100% (all outputs active)
Incorrect connection causes neither high level nor destruction of the outputs.
7.8.4 Parameter assignment
7.8.4.1 Input / output images
Input image
The image comprises 3 slots (n, m, d ≙ start address, see Addressing components
(Page 256)):
● Slot 1: Digital inputs (DI)
– n+0 … n+8 (9 byte)
– X222.P3 - .P10 are rapid inputs
● Slot 2: 2 analog inputs (AI): m+0 … m+7 (8 byte)
● Slot 3: Diagnostics: d+0 .. d+1
Table 7-77 Input image of digital inputs for the 1st I/O module (n=0)
Terminal Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
X111
n+0 Pin10
DI 0.7
Pin9
DI 0.6
Pin8
DI 0.5
Pin7
DI 0.4
Pin6
DI 0.3
Pin5
DI 0.2
Pin4
DI 0.1
Pin3
DI 0.0
n+1 Pin18
DI 1.7
Pin17
DI 1.6
Pin16
DI 1.5
Pin15
DI 1.4
Pin14
DI 1.3
Pin13
DI 1.2
Pin12
DI 1.1
Pin11
DI 1.0
n+2 Pin26
DI 2.7
Pin25
DI 2.6
Pin24
DI 2.5
Pin23
DI 2.4
Pin22
DI 2.3
Pin21
DI 2.2
Pin20
DI 2.1
Pin19
DI 2.0
Anschließbare Komponenten
7.8 PP 72/48D PN
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 207
