Dimension drawing




Figure 7-62 NX10.3 dimensions
7.10.3 Connecting
Power supply X124
Connector designation: X124
Connector type: Screw terminal 2
Max. connectable cross-section: 2.5 mm
2
Table 7-118 Pin assignment for X124
Pin Signal name Meaning
1 + (Voltage input) Electronics power supply
2 + (Voltage input) Electronics power supply
Anschließbare Komponenten
7.10 NX10.3
PPU and components
250 Manual, 05/2015, 6FC5397-2DP40-3BA4

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
