Note
When the system is booting, LEDs H1, H2 and H3 are lit.
7.8.2 Mounting
Mounting
The I/O module is screwed with a mounting plate to the control cabinet wall in the control
cabinet. The module must be installed according to EN 60204.
WARNING
Protection against electric shock
A protective conductor must be connected using the grounding screw.
Mounting versions:
● Portrait mounting at the lateral strap of the mounting plate (2x M5 or M6 screws).
● Flat mounting at the rear wall of the mounting plate (4x M5 or M6 screws).
Anschließbare Komponenten
7.8 PP 72/48D PN
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 195

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
