7.2.4 Parameterization
Input image
The specifications for assigning input and output bytes listed in the tables are defined as
standard addresses in the PLC. Either one MCP USB or one MCP PN can be connected to
the PPU, and therefore only DB1000 and DB1100 are described. To activate the MCP USB
set MD12950[0] = 1. Further information on settings in the machine data can be found in
Section Activating and addressing components (Page 255).
DB1000
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
DBB0 Spindle override Operating mode
D (2
3
) C (2
2
) B (2
1
) A (2
0
) JOG TEACH IN MDI AUTO
DBB1 Machine function
REPOS REF. Var. INC - - - - -
DBB2 - - Spindle
start
Spindle
stop
*)
Feedrate
start
Feedrate
stop
*)
NC start NC stop
*)
DBB3 RESET - Single block Feed override
E (2
4
) D (2
3
) C (2
2
) B (2
1
) A (2
0
)
DBB4 S24 S22 S23 - S31 S34 S37 -
DBB5 S32 S33 S35 Travel com‐
mand in
MCS/WCS
- S39 S38 S36
DBB6 Freely assignable customer keys Reserved
S18 - S7 (coolant) S21 - - - -
DBB7 Freely assignable customer keys
S10 S11 S12 S13 S14 S15 S16 S17
DBB1000 Version information of the MCP USB - byte 0
DBB1001 Version information of the MCP USB - byte 1
DBB1002 Version information of the MCP USB - byte 2
DBB1003 Version information of the MCP USB - byte 3
*) These signals are inverse.
Output image
DB1100
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
DBB0 - - - - Operating mode
JOG TEACH IN MDI AUTO
DBB1 Feedrate
start
Feedrate
stop
*)
NC start NC stop
*)
Machine function -
REPOS REF. Var. INC
DBB2 S22 S31 S34 S37 - Single block Spindle
start
Spindle
stop
*)
Anschließbare Komponenten
7.2 MCP 310 USB
PPU and components
114 Manual, 05/2015, 6FC5397-2DP40-3BA4
