6.8 USB
Use
The USB interfaces correspond to the norm and are, therefore, not described in detail here.
● The X125 USB interface (at the front behind a flap) can be used to connect a USB-
FlashDrive for transferring user and commissioning data.
● The X135 USB interface (at the rear) is available only for service purposes.
Cable specification
Features Variants
Connector type: USB socket - type A
Version: USB 2.0
Current carrying capacity: 0.5 A per connector
Max. data transmission rate 12 Mbit/s
Max. cable length 3 m
Note
The 5 V power supply is designed to be short-circuit proof.
Interface description
6.8 USB
PPU and components
90 Manual, 05/2015, 6FC5397-2DP40-3BA4

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
