Installing
4
Installation notes
PPU modules may only be installed in housings, cabinets or in isolated electrical business
establishments. Housings, cabinets, or isolated electrical business establishments may only
be accessed by trained or authorized personnel.
DANGER
Risk of electric shock
The entire system must be voltage-free when mounting or wiring the SINUMERIK 828D.
Components in the control cabinet
The SINAMICS components and the axis expansion modules are installed in a control cabinet.
References
Notes for mounting components of the SINAMICS S120 product family are contained in the
following manuals:
● SINAMICS S120 Booksize Power Units Manual
● SINAMICS S120 Combi Manual
For further details on the control cabinet installation, refer to:
● "Control Cabinet Integration, SINAMICS S120 Booksize / SIMODRIVE" System Manual
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 43

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
