Cable specification for X100 - X102
Feature Version
Connector type RJ45 socket with 180° cable outlet
Cable type MOTION-CONNECT
Article number 6FX2002-1DC00-1□□0
Max. cable length 70 m
Blanking cover for DRIVE-CLiQ interface: Tyco company, article number: 969556-5
Note
Interfaces X100 to X102
The interfaces X100 to X102 of the PPU do not provide any 24 V supply voltage. Consequently,
no components, such as SME, can be connected here that must be supplied with 24 V via
DRIVE-CLiQ.
Additional references
Further information on the components in this section:
● SINAMICS S120 Control Units and Additional System Components Manual
● SINAMICS S120 Booksize Power Units Manual
● SINAMICS S120 Booksize Power Units with Cold Plate Manual
● SINAMICS S120 Combi Manual
6.6.2 SINAMICS components
Components with DRIVE-CLiQ
As a rule, all SINAMICS components approved for SINUMERIK 828D can be connected using
DRIVE-CLiQ.
Component Description
NX10.3 / NX15.3 Axis expansion module
Active / Basic / Smart Line Mod‐
ules Booksize / Chassis
Line Modules provide the central power supply to the DC link.
Single / Double Motor Modules
Booksize / Chassis
Motor Modules draw their power from the DC link to supply the con‐
nected motors.
SINAMICS S120 Combi The S120 Combi is a compact unit in the Booksize format with inte‐
grated infeed.
Single/Double Motor Modules
Booksize Compact
The Booksize Compact format is the expansion module for the
S120 Combi.
SMC10 / 20 / 30 Cabinet-mounted sensor modules are used when a motor with a
DRIVE-CLiQ interface is not available and when external encoders
are required in addition to the motor encoder.
Interface description
6.6 DRIVE-CLiQ
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 85
