Technical data
8
PPU
Parameter Value
Input voltage 24 V DC + 20% / - 15%
Power consumption, max. 60 W
Power loss 28 W
Cooling Open-circuit ventilation
Degree of protection acc. to EN 60529 IP65 (with closed front cover)
IP20 (rear)
Protection class acc. to EN 61800-5-1 III (DVC A, PELV)
Pollution degree acc. to EN 61800-5-1 2
Climate classification:
● Storage (in transport packaging)
● Transport (in transport packaging)
● Operation
1M2 acc. to EN 60721-3-1
2M3 acc. to EN 60721-3-2
3M1 acc. to EN 60721-3-3
Mounting position Vertical
Dimensions:
● Width
● Height
● Depth
PPU vertical:
● 310 mm
● 380 mm
● 105 mm
PPU horizontal:
● 483 mm
● 220 mm
● 105 mm
Weight, approx. 4.5 kg
Approvals CE, cULus
Basic color of the front 614 Anthracite (similar to RAL 7021)
See also
Further technical data for the PPU can be found in the following sections:
● Transport and Storage Conditions (Page 39)
● Operating Conditions (Page 40)
● Requirements for the power supply (Page 69)
Digital inputs/outputs:
● Technical data (Page 82)
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 259
