7.6.1 Mounting
Dimensions of the electronic handheld handwheel
SLQFRQQHFWRU
0DJQHWLFFODPS
Figure 7-36 Front view and side view
Additional options
Optionally, the handheld electronic handwheel can be stored in a screw-on holder. The holder
is mounted using three M4 screws (included in the scope of delivery).
See also: Mini handheld unit, Chapter "Mounting (Page 181)"
Anschließbare Komponenten
7.6 Electronic handwheel
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 175
