7.6.3 Technical specifications
Handheld electronic handwheel
Parameter Value
Operating voltage 5 V DC ± 5%
Current consumption Max. 80 mA
Limit frequency 10 kHz
Number of pulses 100 S/R
Displacement of phase A to B, typical 90° electrical
Interface RS422
Cable length Max. 25 m
Actuating force 4 Ncm
Speed Max. 1,000 rpm
Protection class I
Degree of protection in acc. with DIN EN 60529/
IEC 60529
IP65
Housing material Thermoplastic
Vibratory load
● Operation
● Transport (in transport packaging)
58 – 200 Hz: 10 m/s
2
9 - 200 Hz: 20 m/s
2
Shock load in acc. with IEC 68-2-27
● Operation
● Transport (in transport packaging)
100 m/s
2
, 11 ms, 6 shocks
300 m/s
2
, 6 ms, 6 shocks
Condensation, splash water, and icing Not permitted
Supply air Without aggressive gases, dusts, and oils
Relative humidity:
● Storage
● Transport
● Operation
5 ... 95 %
5 ... 95 %
5 ... 95 %
Ambient temperature:
● Storage
● Transport
● Operation
-25 ... 55 °C
-40 ... 70 °C
0 ... 55 °C
Dimensions:
● Width
● Height
● Depth
160 mm
85 mm
67 mm
Weight 0.3 kg (without connecting cable)
Approvals CE, cULus
Anschließbare Komponenten
7.6 Electronic handwheel
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 177
