6.3 Ethernet
X130, X127 pin assignment
Pin Signal name Signal type Meaning
1 TX+ O Transmit data +
2 TX- O Transmit data -
3 RX+ I Receive data +
4 NC -
5 NC -
6 RX- I Receive data -
7 NC -
8 NC -
Use
The interfaces are designed for operation in full-duplex mode; in other words, the ports can
be used for the sending as well as for the receiving of data packets. The ports are connected
as an Ethernet terminal with 10/100 Mbit:
● X130 connects the PPU to the plant network.
– The IP address can be freely selected.
– MAC address, see also: Type plate (Page 25).
● X127 is used to connect the following components:
– PG/PC via peer-to-peer with permanently assigned IP address 192,168,215 .1, for
example, for the commissioning software, RCS Commander
– Modem for remote diagnostics
LED status displays
For diagnostic purposes, the RJ45 sockets are each equipped with a green and a yellow LED.
This allows the following status information about the respective Ethernet port to be displayed:
Table 6-5 LED status displays
LEDs Status Meaning
Green Lit 10 or 100 Mbit link available
Off Missing or faulty link
Yellow Lit Receive or transmit activity
Off No activity
