7.3.5 Technical data
MCP 483C PN
Parameter Value
Input voltage 24 V DC
Power consumption, max.
● Board
● Illumination
● Handwheels
● Total
5 W
43.2 W (6 x 7.2 W) *)
2 x 0.9 W
50 W
Vibratory load:
● Operation
● Transport (in transport packaging)
10 – 58 Hz: 0.15 mm
58 – 200 Hz: 2 g (acc. to EN 60721-3-3)
5 – 9 Hz: 6.2 mm
9 – 200 Hz: 2 g (acc. to EN 60721-3-2)
Shock load:
● Operation
● Transport (in transport packaging)
15 g, 11 ms, 18 shocks (acc. to EN 60721-3-3)
15 g, 6 ms, 18 shocks (acc. to EN 60721-3-2)
Protection class acc. to EN 61800-5-1 III (DVC A, PELV)
Degree of protection acc. to DIN IEC 529 IP54 (front)
IP00 (rear)
Condensation, splash water and icing Not permissible
Relative humidity:
● Storage
● Transport
● Operation
5 ... 95 %
5 ... 95 %
5 ... 95 %
Supply air Without aggressive gases, dusts and oils
Cooling By natural convection
Ambient temperature:
● Storage
● Transport (in transport packaging)
● Operation
– Front
– Rear
-25 °C ... 55 °C
-40 °C ... 70 ºC
0 ... 45 ºC
0 ... 55 °C
Dimensions:
● Width
● Height
● Depth
483 mm
155 mm
55 mm
Weight, approx. 1.8 kg
Approvals CE, cULus
Anschließbare Komponenten
7.3 MCP 483C PN
PPU and components
134 Manual, 05/2015, 6FC5397-2DP40-3BA4
