Siemens SINUMERIK 828D Manual

Spare parts and accessories
9
9.1 Ordering data
Ordering data of the components
Die SINUMERIK 828D wird im Paket mit Antrieben, Motoren und Zubehör vermarktet. Nehmen
Sie dazu bitte Kontakt mit Ihren zuständigen Siemens Vertriebsbeauftragten auf.
Designation Article number
Panel Processing Unit without system software
● PPU 241.3 BASIC horizontal
6FC5370-3AA30-0AA0
● PPU 240.3 BASIC vertical
6FC5370-4AA30-0AA0
● PPU 261.3 horizontal
6FC5370-5AA30-0AA0
● PPU 260.3 vertical
6FC5370-6AA30-0AA0
● PPU 281.3 horizontal
6FC5370-7AA30-0AA0
● PPU 280.3 vertical
6FC5370-8AA30-0AA0
CompactFlash card with system software and license
● For PPU 241.3 / PPU 240.3: Turning
6FC5835-1GY40- ☐ YA0
● For PPU 241.3 / PPU 240.3: Milling
6FC5835-2GY40- ☐ YA0
● For PPU 261.3 / PPU 260.3: Turning
6FC5834-1GY40- ☐ YA0
● For PPU 261.3 / PPU 260.3: Milling
6FC5834-2GY40- ☐ YA0
● For PPU 281.3 / PPU 280.3: Turning
6FC5833-1GY40- ☐ YA0
● For PPU 281.3 / PPU 280.3: Milling
6FC5833-2GY40- ☐ YA0
Komponenten
Designation Article number
Machine control panels:
● MCP 483 USB
6FC5303-0AF32-0AA0
● MCP 310 USB
6FC5303-0AF33-0AA0
● MCP 483C PN
6FC5303-0AF22-0AA1
● MCP 310C PN
6FC5303-0AF23-0AA1
Interface module MCP Interface PN 6FC5303-0AF03-0AA0
Handheld electronic handwheel 6FC9320-5DE02
Mini handheld unit:
● With spiral connection cable
6FX2007-1AD03
● With straight cable
6FX2007-1AD13
I/O modules:
● PP 72/48D PN (digital)
6FC5311-0AA00-0AA0
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 261

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
