7.9.3.2 X2 PROFINET
Requirement
The I/O module has certified PROFINET interfaces, however their functionality cannot be fully
utilized within the scope of the SINUMERIK 828D control system. Networking within
SINUMERIK 828D is performed via a PLC I/O interface, which is based on PROFINET.
Data transmission rate and cables
The interfaces are designed for full-duplex mode; in other words, the ports can both transmit
and receive. When connecting I/O modules to the SINUMERIK 828D, please use the
preassembled SINAMICS DRIVE-CLiQ signal cables; from a technical point of view, these are
also suitable for use with PROFINET:
● Article number: 6FX2002-1DC00-...
● The transmission characteristics of these cables meet the requirements of CAT5.
● Data transmission speed: 100 Mbps (fast Ethernet).
● The maximum length of the connections between the end device and network component
or between two network components (e.g. switch ports) must not exceed 70 m.
Pin assignment
Table 7-91 Pin assignment - PROFINET X2, Port 1 and Port 2
Pin Signal name Signal type Meaning
1 TX+ O Transmit data +
2 TX- O Transmit data -
3 RX+ I Receive data +
4 N.C. - Not assigned
5 N.C. - Not assigned
6 RX- I Receive data -
7 N.C. - Not assigned
8 N.C. - Not assigned
LED displays
For diagnostic purposes, the RJ45 sockets are each equipped with a green and a yellow LED.
This allows the following information on the respective PROFINET port to be displayed:
Table 7-92 PROFINET ports LED displays
Name Color Status Meaning
Link Green Lit 100 Mbit link available
Off Missing or faulty link
Anschließbare Komponenten
7.9 PP 72/48D 2/2A PN
PPU and components
222 Manual, 05/2015, 6FC5397-2DP40-3BA4
