7.4.5 Technical data
MCP 310C PN
Parameter Value
Input voltage 24 V DC
Power consumption, max.
● Board
● Illumination
● Handwheels
● Total
5 W
43.2 W (6 x 7.2 W) *)
2 x 0.9 W
50 W
Vibratory load:
● Operation
● Transport (in transport packaging)
10 – 58 Hz: 0.15 mm
58 – 200 Hz: 2 g (acc. to EN 60068-2-6 test Fc)
5 – 9 Hz: 3.5 mm
9 – 200 Hz: 1 g (acc. to EN 60068-2-6)
Shock load:
● Operation
● Transport (in transport packaging)
15 g, 11 ms, 18 shocks according to EN 60068-1
15 g, 11 ms, 18 shocks according to EN 60068-2-27
Protection class acc. to EN 61800-5-1 III (DVC A, PELV)
Degree of protection acc. to DIN IEC 529 IP54 (front)
IP00 (rear)
Condensation, spraying water, and icing Not permitted
Relative humidity:
● Storage
● Transport
● Operation
5 ... 95 %
5 ... 95 %
5 ... 95 %
Supply air Without aggressive gases, dusts, and oils
Cooling By natural convection
Ambient temperature:
● Storage
● Transport (in transport packaging)
● Operation
– Front
– Rear
-25 °C ... 55 °C
-40 °C ... 70 ºC
0 ... 45 ºC
0 ... 55 °C
Dimensions:
● Width
● Height
● Depth
310 mm
175 mm
55 mm
Weight, approx. 1.2 kg
Approvals CE, cULus
Anschließbare Komponenten
7.4 MCP 310C PN
PPU and components
152 Manual, 05/2015, 6FC5397-2DP40-3BA4
