5.3 Topology rules for Safety Integrated functions
Number
of axes
Port 1 at the PPU
X100
Port 2 at the PPU
X101
Port 3 at the PPU
X102
Example in the figure:
SINAMICS S120 booksize
5 1 x LM
4 x MoMo
1 x SMy at the 4th MoMo
1 x TM54F
1x MoMo
1 x Hub DMx
4 x SMy at the Hub DMx
not used ---
6 1 x LM
4 x MoMo
1 x SMy at the 4th MoMo
1 x TM54F
2x MoMo
1 x Hub DMx
5 x SMy at the Hub DMx
not used ---
7 1 x LM
4 x MoMo
1 x SMy at the 4th MoMo
1 x TM54F
2x MoMo
1 x Hub DMx
5 x SMy at the Hub DMx
1 x NX10.3
1 x TM54F
1 x MoMo
1 x SMy at the MoMo
---
8 1 x LM
4 x MoMo
1 x SMy at the 4th MoMo
1 x TM54F
1x MoMo
1 x Hub DMx
4 x SMy at the Hub DMx
1 x NX10.3
1 x TM54F
3 x MoMo
1 x SMy at NX10.3
1 x SMy at TM54F
1 x SMy at the 3rd MoMo
Topology with SINAMICS
S120 Booksize 5+3 axes
(Page 63)
8 1 x LM
4 x MoMo
1 x SMy at the 4th MoMo
1 x TM54F
2x MoMo
1 x Hub DMx
5 x SMy at the Hub DMx
1 x NX10.3
1 x TM54F
2 x MoMo
1 x SMy at NX10.3
1 x SMy at the 2nd MoMo
Topology with SINAMICS
S120 Booksize and 6+2
axes (Page 63)
SINAMICS S120 Combi
3 3x Combi
1xSMy at the Combi
not used 1 x TM54F
1 x Hub DMx
2 x SMy at the Hub DMx
---
4 3x Combi
1xSMy at the Combi
1 x booksize compact 1 x TM54F
1 x Hub DMx
3 x SMy at the Hub DMx
---
4 4x Combi
1xSMy at the Combi
not used 1 x TM54F
1 x Hub DMx
3 x SMy at the Hub DMx
---
5 4x Combi
1xSMy at the Combi
1 x booksize compact 1 x TM54F
1 x Hub DMx
4 x SMy at the Hub DMx
---
6 4x Combi
1xSMy at the Combi
2 x booksize compact 1 x TM54F
1 x Hub DMx
5 x SMy at the Hub DMx
---
Rules for permitted topologies
5.3 Topology rules for Safety Integrated functions
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 59
