Page #228 background imageLoading...
Page #228 background image
NOTICE
Protection against short circuit
A max. current of I
out
= 0.25 A at X111, X222, X333 where the demand factor is 100%: Pin 2
must not be exceeded.
Characteristics:
No galvanic isolation.
Protection against: Short-circuit, overtemperature, and loss of ground.
Automatic disconnection in case of undervoltage.
Technical data:
Table 7-97 Electrical specification of the digital outputs
Digital outputs min. Typical max. Nominal
High-level voltage (U
H
) V
CC
- 3 V
1)
V
CC
24 V
Output current I
OUT
-- -- 250 mA
2)
--
Voltage with low level (U
L
) -- -- -- Output open
Leakage current at low level -- 50 μA 400 μA --
Signal delay time T
PHL
-- 0.5 ms -- --
Maximum switching frequency
Resistive load -- -- 100 Hz --
Inductive load -- -- 2 Hz --
Lamp -- -- 11 Hz --
1)
U
H_typical
= V
CC
- I
OUT
× R
ON
V
CC
: Current operating voltage
I
OUT
: Output current
Maximum short-circuit current: 4 A (max. 100 μs, V
CC
= 24 V)
R
ON
: Maximum internal resistance = 0.4 Ω
2)
Where demand factor is 100% (all outputs active)
Incorrect connection causes neither high level nor destruction of the outputs.
7.9.3.6 Analog X3 inputs/outputs
Cable specification
Connectors: 12-pin socket/plug combination
Cable: shielded
max. cable length: 30 m
max. connectable core cross-section: 0.5 mm
2
Anschließbare Komponenten
7.9 PP 72/48D 2/2A PN
PPU and components
228 Manual, 05/2015, 6FC5397-2DP40-3BA4
