7.9.4.5 Examples
Measured values and responses
The following examples for assigning parameters to analog inputs/outputs are provided for the
I/O module with device number "7".
Example for operating mode voltage measurement
Address Voltage ±10 V
0 V 2.5 V 10 V 12 V
Operating mode QB72 16#55 16#55 16#55 16#55
Format QB73 16#1 16#1 16#1 16#1
Value QW76 16#0 16#199B 16#6666 16#7AE1
Value QW78 16#0 16#199B 16#6666 16#7AE1
Operating mode IB72 16#55 16#55 16#55 16#55
Format IB73 16#1 16#1 16#1 16#1
Value IW76 16#0 16#66D 16#19B5 16#0
Value IW78 16#0 16#66D 16#19B5 16#0
Diagnostics IB50 - - - 16#2
IB51 16#0 16#0 16#0 16#7
PNFault LED OFF OFF OFF ON
Troubleshooting Deactivating/
activating
Example for operating mode current measurement
Address Current 20 mA
0 mA 5 mA 20 mA 22 mA
Operating mode QB72 16#AA 16#AA 16#AA 16#AA
Format QB73 16#1 16#1 16#1 16#1
Value QW76 16#0 16#199B 16#6666 16#70A5
Value QW78 16#0 16#199B 16#6666 16#70A5
Operating mode IB72 16#AA 16#AA 16#AA 16#AA
Format IB73 16#1 16#1 16#1 16#1
Value IW76 16#0 16#665 16#1996 16#0
Value IW78 16#0 16#665 16#1996 16#0
Diagnostics IB50 - - - 16#2
IB51 16#0 16#0 16#0 16#7
Anschließbare Komponenten
7.9 PP 72/48D 2/2A PN
PPU and components
242 Manual, 05/2015, 6FC5397-2DP40-3BA4

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
