Table 6-3 Technical data of the DC power supply
Rated voltage According to EN 61131-2 24 V DC
Voltage range (mean value) 20.4 VDC to 28.8 V DC
Voltage range (dynamic) 18.5 to 30.2 V DC
Voltage ripple peak-to-peak 5% (unfiltered 6-pulse rectifica‐
tion)
Booting time at POWER ON Any
Non-periodic overvoltages ≤ 35 V
Duration of overvoltage ≤ 500 ms
Recovery time ≥ 50 s
Events per hour ≤ 10
Transient voltage interrup‐
tions
Idle time ≤ 3 ms
Recovery time ≥ 10 s
Events per hour ≤ 10
6.2.2 Connecting the power supply
Cable specification
DANGER
Protective separation
The 24 V direct voltage must be configured as an extra-low-voltage with protective separation
- DVC A or PELV.
The required 24 VDC load power supply is wired to the screw-type terminal block (X1).
Use flexible cables with a cross-section of 0.25 to 2.5 mm
2
(or AWG 23 to AWG 13) for wiring
the power supply according to the maximum occurring current.
If you only use one wire per connection, a ferrule is not required. The following wire-end ferrules
are permissible: Without an insulating collar in accordance with DIN 46228, Form A, long
version
Table 6-4 Cable specification for X1
Features Version
Connection option Up to 2.5 mm
2
Current carrying capacity max. 10 A
Max. cable length 10 m
Interface description
6.2 Power supply connection
PPU and components
70 Manual, 05/2015, 6FC5397-2DP40-3BA4
