Siemens SINUMERIK 828D Manual

Designation Article number
● PP 72/48D 2/2A PN (analog)
6FC5311-0AA00-1AA0
Increased number of axes:
● Numeric Control Extension NX10.3
6SL3040-1NC00-0AA0
Accessories
Designation Article number
CompactFlash card (empty), 2 GB 6FC5313-5AG00-0AA2
CompactFlash card (empty as user memory), 8 GB 6FC5313-6AG00-0AA0
Front flap with fastening 6FC5348-2AA00-0AA0
Set of clamps (9x) 6FC5248-0AF14-0AA0
USB flash drive, 8 GB 6ES7648-0DC50-0AA0
SENTRON PAC3200 Power Monitoring Device 7KM2112-0BA00-3AA0
SENTRON PAC4200 Power Monitoring Device 7KM4212-0BA00-3AA0
PROFINET Switched Ethernet expansion module 7KM9300-0AE00-0AA0
MODEM MD720 GSM/GPRS modem 6NH9720-3AA01-0XX0
ANT794-4MR antenna 6NH9860-1AA00
RS232 modem cable 6NH7701-5AN
SIMATIC DP PN/PN coupler 6ES7158-3AD01-0XA0
Terminal strip converter, 50-pin 6EP5406-5AA00
Cable set comprising:
● 6 m ribbon cable, 50-pin
● 8 insulation displacement connectors, 50-pin
6EP5306-5BG00
IP20 PLC I/O interface connecting cable (corresponds to DRIVE-
CLiQ signal cable)
6FX2002-1DC00-...
Blanking plates for the DRIVE-CLiQ interface 6SL3066-4CA00-0AA0
Stabilized power supply SITOP lite 10 A
24 V DC, 1-phase
6EP1334-1LB00
Stabilized power supply SITOP smart 10 A
24 V DC, 1-phase
6EP1334-2BA01
Stabilized power supply PSU100S 20 A
24 V DC, 1-phase
6EP1336-2BA10
Stabilized power supply PSU300S 10 A
24 V DC, 3-phase
6EP1434-2BA10
Stabilized power supply PSU300S 20 A
24 V DC, 3-phase
6EP1436-2BA10
Spare parts and accessories
9.1 Ordering data
PPU and components
262 Manual, 05/2015, 6FC5397-2DP40-3BA4

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
