Table 7-10 Assignment of connector X60
Pin Name Type Meaning
1 P5V V 5 V power supply
2 M V Ground
3 HW1_A I Handwheel pulses track A
4 HW1_XA I Handwheel pulses track A (negated)
5 N.C. - Not assigned
6 HW1_B I Handwheel pulses track B
7 HW1_XB I Handwheel pulses track B (negated)
8 N.C. - Not assigned
9 P5V V 5 V power supply
10 N.C. - Handwheel 2 pulses track A (negated)
11 M V Ground
12 N.C. - Not assigned
13 N.C. - Not assigned
14 N.C. - Not assigned
15 N.C. - Not assigned
Switch S1
The handwheel signal type is set with switch S1.
Closed differential interface
Open TTL interface
Switch S1 is closed when supplied ex works.
Switch S2
Switch position: "ON" is at the top.
Table 7-11 Switch S2 is set as delivered
1 2 3 4 5 6 7 8 9 10 Meaning
ON ON PLC I/O Interface
OFF OFF OFF OFF OFF OFF OFF OFF PROFINET address "0"
The two switches S2-9 and S2-10 must remain "ON".
The switches S2-1 to S2-8 define the PROFINET address. For a SINUMERIK 828D,
the address "64" must always be assigned to the MCP.
Anschließbare Komponenten
7.3 MCP 483C PN
PPU and components
130 Manual, 05/2015, 6FC5397-2DP40-3BA4
