CAUTION
Do not connect any relays, valves or other inductive loads.
Connector designation: X53, X54
Connector type: 4-pin plug connector
Table 7-25 Assignment of connector X53
Pin Signal name Signal type Meaning
1 KT-OUT1
O
Output 1 lamp
2 KT- OUT2 Output 2 lamp
3 KT- OUT3 Output 3 lamp
4 M V Ground
Table 7-26 Assignment of connector X54
Pin Signal name Signal type Meaning
1 KT-OUT4
O
Output 4 lamp
2 KT- OUT5 Output 5 lamp
3 KT- OUT6 Output 6 lamp
4 M V Ground
X60 handwheel
Via X60, you can connect one handwheel either with TTL or difference signals.
Note
The handwheel is supplied by the MCP module with 5 V / 100 mA. An external power supply
is not permitted.
NOTICE
Handwheel connections
The SINUMERIK 828D software can process up to three handwheels. You can connect two
handwheels to the PPU. You can connect an additional handwheel to the machine control
panel.
Connector designation: X60
Connector type: 15-pin Sub-D socket
Anschließbare Komponenten
7.4 MCP 310C PN
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 147
