Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
EB125 - - - X31
pin 6
1)
X31
pin 7
1)
X31
pin 8
1)
X31
pin 9
1)
X31
pin 10
1)
Signals marked with * are inverse signals.
1) If the 4-stage rotary spindle override switch on X31 is replaced by a 5-stage rotary switch, the input information here
can be measured in 5 stages.
Input image of the handwheel
Table 7-31 Input image for handwheel data
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
EB m + 0 Handwheel 1 counter status
(16-bit signed, low-order byte equals byte m + 0)
EB m + 1
EB m + 2 Handwheel 2 counter status
(16-bit signed, low-order byte equals byte m + 2)
EB m + 3
Note
Within the SINUMERIK control, the handwheel data is processed directly by the NC and is not
available to the PLC.
Output image
Table 7-32 Output image MCP 310C PN
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
AB112 * NC
stop Spindle -
Spindle
100% Spindle +
Single
block JOG MDI AUTO
AB113 NC
start
Spindle
right
* Spindle
stop
Spindle
left
RESET REF REP Teach
IN
AB114 Feed
start
* Feed
stop
INC VAR - INC 1000 INC 100 INC 10 INC 1
AB115 - - - - - - - -
AB116 + _ Rapid tra‐
verse
KT-OUT5 KT-OUT4 KT-OUT3 KT-OUT2 KT-OUT1
AB117 T16 KT-OUT6 6 5 4 Z Y X
AB118 Freely assignable customer keys
T9 T10 T11 T12 WCS
MCS
T13 T14 T15
AB119 Freely assignable customer keys
T1 T2 T3 T4 T5 T6 T7 T8
Signals marked with * are inverse signals
Anschließbare Komponenten
7.4 MCP 310C PN
PPU and components
150 Manual, 05/2015, 6FC5397-2DP40-3BA4
