Siemens SINUMERIK 828D Manual

Analog inputs
Table 7-113 Measured values in the voltage measurement operating mode
16 bit value (hex.) 16 bit value (dec.) Factor Voltage value [V]
Overflow - Deactivation
Overrange - Up to 11.75 V
0x19B5 6581
0.00151947
10 V
0x0CDA 3291 5 V
0x066D 1645 2.5 V
0x0000 0 0 V
0xF993 -1645 -2.5 V
0xF326 -3291 -5 V
0xE64B -6581 -10 V
Underrange - Up to -11.75 V
Underflow - Deactivation
Table 7-114 Measured values in the current measurement operating mode
16 bit value (hex.) 16 bit value (dec.) Factor Current value [V]
Overflow - Deactivation
Overrange - Up to 23.5 mA
0x1999 6553
0.003051758
20 mA
0x0CCC 3277 10 mA
0x0000 0 0 mA
0xF333 -3277 -10 mA
0xE666 -6553 -20 mA
Underrange - Up to -23.5 mA
Underflow - Deactivation
Table 7-115 Measured values in the "temperature measurement" operating mode
16 bit value (hex.) 16 bit value (dec.) Factor Temperature value [V]
Overflow
0x0A28 2590
0.1
259 ℃
0x03E8 1000 100 °C
0x01F4 500 50 ℃
0x0000 0.0 0 °C
0xFE0C -500 -50 ℃
0xFC18 -1000 -100 °C
0xF830 -2000 -200 ℃
Underflow
Anschließbare Komponenten
7.9 PP 72/48D 2/2A PN
PPU and components
240 Manual, 05/2015, 6FC5397-2DP40-3BA4

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
