Siemens SINUMERIK 828D

PN component Bus Device name IP address Input addresses Output addresses
3rd PP module digital PN pp72x48pn7 7 18 … 26 12 … 17
4th PP module digital PN pp72x48pn6 6 27… 35 18 … 23
5th PP module digital PN pp72x48pn5 5 36 … 44 24 … 29
Unassigned 45 30 … 55
Index d:
1st PP module diagnostics PN pp72x48pn9 9 46 … 47 --
2nd PP module diagnostics PN pp72x48pn8 8 48 … 49 --
3rd PP module diagnostics PN pp72x48pn7 7 50 … 51 --
4th PP module diagnostics PN pp72x48pn6 6 52 … 53 --
5th PP module diagnostics PN pp72x48pn5 5 54 … 55 --
Index m:
1st PP module analog PN pp72x48pn9 9 56 … 63 56 … 63
2nd PP module analog PN pp72x48pn8 8 64 … 71 64 … 71
3rd PP module analog PN pp72x48pn7 7 72 … 79 72 … 79
4th PP module analog PN pp72x48pn6 6 80 ... 87 80 ... 87
5th PP module analog PN pp72x48pn5 5 88 … 95 88 … 95
PN/PN coupler * PN pn-pn-coupler20 20 96 … 111 96 … 111
External machine control panel PN mcp-pn64 64 112 … 125 112 … 121
Reserved -- -- 126 … 131 122 ... 123
SENTRON PAC4200 * PN pac4200-pn21 21 132 ... 143 132 ... 143
SENTRON PAC3200 * PN pac3200-pn22 22 144 ... 155 144 ... 155
The Index n, m, d is always the start address of the address range.
*) The IP address of these components is not set using a switch but rather configured appropriately.
Anschließbare Komponenten
7.11 Activating and addressing components
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 257
