Parameter SENTRON PAC3200 SENTRON PAC4200
Measuring inputs for current
3 AC; CAT III
x/1 A or x/5 A
Current direction, programmable ✓ ✓ per phase
Measurement using current transformers ✓ ✓
Dimensions (W x H x D) 96 x 96 x 56 mm 96 x 96 x 82 mm
Overall depth
● Without module
● With module
51 mm
73 mm
77 mm
99 mm
Protection class II
Degree of protection at front IP65
Slots for expansion modules 1 2
Operating temperature -10 to +55° C
Relative humidity in operation no conden‐
sation
95%
Degree of contamination 2
Approvals CE, cULus, C-Tick, GOST CE, cULus, GOST
Further information
You can find additional information about SENTRON PAC in the context of SINUMERIK in the
Ctrl-Energy System Manual as well as in the Internet at:
● SENTRON PAC3200 (http://support.automation.siemens.com/WW/view/de/25240652)
● SENTRON PAC4200 (http://support.automation.siemens.com/WW/view/de/31675630)
Spare parts and accessories
9.4 SENTRON PAC3200/PAC4200
PPU and components
270 Manual, 05/2015, 6FC5397-2DP40-3BA4
