Note
The user must consider interference radiation for the complete system. Particular attention
should be paid to cabling. Please contact your sales representative for assistance and support.
If compliance with limit value class C2 is required, please contact your local Siemens sales
partner.
Literature:
Please see the relevant SINAMICS documentation for EMC notes on how to deal with line
filters and reactors.
Application planning
3.2 Climatic and mechanical environmental conditions
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 41

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
