5]PD[
$
$
① Mounting frame
② Tensioner (10 parts)
③ Seal
④ Shield contact
⑤ Grounding screw M5
⑥ Interfaces
Figure 4-3 Horizontal PPU mounting
Installing
4.1 Mounting positions
PPU and components
46 Manual, 05/2015, 6FC5397-2DP40-3BA4
