Use
The following assignment applies to the terminals:
● Ten signals can each be assigned to connectors X122 and X132:
– Six digital inputs
– Four bidirectional digital inputs/outputs
These twelve inputs and eight inputs/outputs are used for drive control.
● For the X242 connector, four inputs and four outputs are available for the NC.
● For the X252 connector, four inputs and two outputs are available for the NC.
Cable specification at X122, X132, X242 and X252
Please note the following:
● Use flexible cables with a cable cross-section of at least 0.25 mm
2
● Ferrules are not required.
● You can use ferrules without an insulating collar in accordance with DIN 46228, Form A
long version.
● You can connect two cables each with a cross section of 0.25 mm
2
in one ferrule.
Features Version
Connection option Up to 0.5 mm
2
Current carrying capacity 4 A max. 4 A
Max. cable length 30 m
Wiring the digital inputs/outputs
Tools required: 3.5-mm screwdriver or power screwdriver
Procedure:
1. Strip off 6 mm of cable insulation and, if necessary, press on a ferrule.
2. Wire the digital inputs of the interface for connection of the sensors.
3. Wire the digital outputs of the interface for connection of the actuators.
4. Insert the cable into the corresponding screw terminal.
References
More information about digital inputs/outputs can be found in:
Basic Functions Function Manual, "PLC for SINUMERIK 828D" (P4)
Interface description
6.5 Digital inputs/outputs
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 79
