Parameter Value
Voltage 18 V to 30 V
Load current per output, maximum 0.5 A
Load current per connector, maximum 1 A
Signal propagation times L → H: 50 μs
H → L: 200 μs
Galvanic isolation Yes: The reference potential is terminal1M/1P24 (24 V
DC)
Digital outputs
Table 6-8 Technical data of the digital outputs at X242/X252
Parameter Value
Voltage 18 V to 30 V
Load current per output, maximum 0.5 A
Load current per connector, maximum 1 A
Signal propagation times L → H: 50 μs
H → L: 200 μs
Galvanic isolation Yes: The reference potential is terminal 3M/3P24 (24
V DC).
Interface description
6.5 Digital inputs/outputs
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 83

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
